NYB-12 Vertical Leaf Oil Filter 12m2 Filtration Area 2-4T/H Capacity

NYB high efficiency plate hermetic filter is a high-efficient, energy-saving and hermetically operated fine filter equipment. It is widely used in chemical, petroleum, painting, foodstuff, pharmaceutical and many other industries.

The filter is composed of shell, filtration plate, cover, and automatic dump device. Among them, the filtration plate is made of many layers of stainless steel filtration materials, and they are installed on the central liquid collection pipe, so it can be dismantled for cleaning very conveniently.

• No cloth or filter paper required, significantly reducing filtration costs
• Fully closed operation is environmentally friendly with no material loss
• Vibration residue discharge reduces labor intensity and enables continuous operation
• Pneumatic valve residue discharge minimizes worker labor intensity
• Capable of activated carbon (carclazyte) filtering or bleaching filtering, completely replacing plate and frame filters

• 11 filter leaves provide 12 sqm filtration area
• Leaves surrounded by heavy box channel 1.8 mm material 316L
• Topside of leaf with reinforcement and one vibrator fork per leaf (SS 316 material)
• Leaf bottom with outlet nozzle featuring "O"ring seal (SS 316 nozzle with Viton rubber "O"ring)

• DN 400 butterfly valve WAFER TYPE for dry cake discharge
• High quality butterfly valve with NH-S seat material (up to 150°C)
• Includes pneumatic actuator (double acting type) with 5.5 Bar air supply

• Inquiry and consulting support
• Sample testing support
• Factory visit opportunities

• Installation and operation training
• Overseas engineer support available
• Prompt response within 2 hours for reported issues
• On-site problem resolution until customer satisfaction

Juneng Machinery (China) Co., Ltd., established in 2006, is a professional manufacturer engaged in the research, development, production, sale and service of Filters, Separators, Decanter centrifuges and pumps. We have four factories located in Nanjing and Yixing City with convenient transportation access.

Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements. We have obtained CE certificates, ASME U certificate and ISO 9001 certificate. Our products sell well throughout China and are exported to USA, Germany, Korea, Japan, and other countries.

We welcome OEM and ODM orders. Our customer service center is available to discuss your sourcing requirements.

• Factory visit/audit available prior to purchase
• Material inspection during manufacturing and prior to shipment
• Strict compliance to technical requirements
